SVERO
Art no. 1427
Chain Hoist 20 000 kg, lift 3 m, manual
Chain hoist 20000 kg from Svero for extremely heavy lifting during, for example, installations of large machines.
34 927 SEK
Excl. VATOrder item
Send quotation request
Print If you have questions Contact us
Description
- can be ordered with adapted lifting and/or operating height
- fits most beam trollies and beam clamps
- 0.5-20 tons can be obtained with overload protection
- powder-coated housing in steel provides very good rust protection
- swivelling hooks with safety latch
- safe, well protected, automatic load pressure brake
- load chain treated with COROLIM® provides excellent corrosion protection
- double layers on the chain link ensure perfect balance and smooth running
- working temperature -10° C up to +50° C
- traceable with unique SVERO serial number
- each chain hoist is dynamically test loaded with 1.5 x WLL before leaving production
- test and CE certificates and manual included
Specifications
Art no.
1427
WLL
20000
Test load
30000
Safety factor
4:1
Standard lift
3
Standard maneuver chain
3
Falls
8
Load chain
9 x 27
Hand chain
5 X 23,7
Weight, net
150
Marking
CE, WLL
Standard
SS-EN 13157
Brand
SVERO
