SVERO
Art no. 20123AS
Beam Trolley 500 kg, 46-160 mm, stainless
SVEROs 500 kg beam trolley in stainless steel. The low-built 3-part construction is easy to assemble. An all-round Svero beam trolley for, for example, the smaller workshop or pump station.
11 326 SEK
Excl. VATIn stock
–
+
Manual
Print Description
- fits most chain hoists, both manual and electrical
- fits IPE, HEA, HEB and INP beams
- powder-coated steel sides
- adjustable left and right threaded suspension bolt
- test loaded with 1.5 x WLL
- working temperature -10° C up to +50° C
- test and CE certificates and manual included
- traceable with unique SVERO serial number
Specifications
Art no.
20123AS
WLL
500 kg
Beam width
46-160 mm
Test load
750 kg
Safety factor
4:1
Min. curve radius
1,0 m mm
Weight, net
6 kg
Marking
CE, WLL, BEAM WIDTH
Standard
SS-EN 13157
Brand
SVERO
