SVERO
Art no. 20173AS
Beam Trolley 3000 kg, 74-180 mm, stainless
SVEROs beam trolley 3000 kg in stainless steel. For heavier industry and, for example, maintenance and service of larger machines. The low-built 3-part construction is easy to assemble.
28 619 SEK
Excl. VATOrder item
–
+
Send quotation request
Print If you have questions Contact us
Description
- fits most chain hoists, both manual and electrical
- fits IPE, HEA, HEB and INP beams
- powder-coated steel sides
- adjustable left and right threaded suspension bolt
- test loaded with 1.5 x WLL
- working temperature -10° C up to +50° C
- test and CE certificates and manual included
- traceable with unique SVERO serial number
Specifications
Art no.
20173AS
WLL
3000
Beam width mm
74-180
Test load
4500
Safety factor
4:1
Min. curve radius
2,2 m
Weight, net
31.5
Marking
CE, WLL, BEAM WIDTH
Standard
SS-EN 13157
Brand
SVERO
